安装和使用 :
MZ 系列凸轮离合器两端配有防尘轴承,內部已经注入特殊的润滑脂,使用时不需要润滑。
与皮带轮、齿轮或链轮配合时,將离合器插入皮带轮、齿轮或链轮的孔(具有 JIS 標准 f6 级公差)
並將螺栓(高抗拉强度)旋入离合器端面的牙孔內来紧固。 外部载荷要使用其他的装置来支撑,不
能直接作用在凸轮离合器上。 离合器与轴的联结仅能使用平键,请勿使用锥形键。
当將离合器安装到轴上时,应將推力作用於离合器的內圈,请勿作用於外圈。
此系列凸轮离合器的工作环境温度:-5℃至 40℃, 也可根据用户需要,设计、制造非标离合器。
单向离合器是一种精密装置,它能在一个方向传动扭矩而在反方向超速运转。它具备处理超越运转、
反向制动、以及分离操作三种基本功能。
应用范围
广泛用于机床、包装机械、印刷机械、轻工机械、纺织机械、石化机械、水泥机械、治金机械、连
铸机、起重运输机械、减速机、发电设备及试验台等机械传动中 。
Installation and use:
MZ series CAM with dustproof bearing on both ends of the clutch, internal has special grease injection, when
using do not need lubrication.Cooperate with pulley, gear or sprocket, insert the clutch pulley, gear or sprocket holes
(with the JIS standard grade f6 tolerance) and bolt (high tensile strength) end of the screwing in clutch tooth hole to
tighten.To use other devices to support external load, and no direct effect on the CAM clutch.The clutch and the
shaft coupling can only use flat key, do not use taper key.When the clutch is installed on the shaft, the thrust on the
clutch should be inner ring, please do not apply to outer ring.This series of CAM clutch working environment
temperature: - 5 ℃ to 40 ℃, can also according to user needs, design, manufacture non-standard clutch.A one-way
clutch is a precision device, it can drive torque in one direction and in the opposite direction in overdrive.It has
